In stock - ready to ship
International shipping is available
Applications
- Lime-cement plaster < 3 mm;
- Lime-cement plaster > 3 mm;
- Adhesive mortar;
- Mortar for frame injection molding;
- Dry clay plaster;
- Wet plastic clay plaster;
- Masonry mortar;
- Fireproof mortar;
- Concrete repair mortar;
- Screed 35 l;
- Screed 60 l;
- Thin screed;
- Self-leveling floors;
- Mortars mixed on site.
Maximum grain size
6 mm
Working pressure
25 bar
Productivity at 200 rpm
60 l/min
Productivity at 400 rpm
120 l/min
Rubber Hardness
Hard
Connection Type
L
Rotation Direction
Clockwise
Rotor Material
steel or cast iron (depending on modification)
Stator Material
steel housing + rubber inner lining
Stator color
brick-red
ZP 3
How to order
We will select a kit for your equipment.
The kit can be ordered for scheduled replacement, plastering machine repair or restoration of stable material feed. If the exact model is unknown, we can check compatibility by photo, part marking or equipment model.
By equipment model
Specify the model of the plastering machine or mortar pump so we can check the kit compatibility.
By photo of the part
If there is no marking, you can send a photo of the current rotor, stator or complete kit.
By specifications
We can process the request based on parameters: grain size, pressure, productivity and material type.
For regular supplies
Suitable for service companies, construction organizations and technical departments that maintain equipment.
Request
Request a price
Fill out the form and attach the available data. If there is no technical documentation, a photo of the part, equipment model or material description is sufficient.
What helps calculate the price faster?
Equipment model, photo of the current kit, quantity, delivery country, material type and desired delivery time
Process
Clear path from request to delivery
1
Request analysis
We check the kit type, equipment model and operating conditions.
2
Data clarification
If necessary, we clarify the material, productivity, pressure, quantity and delivery region.
3
Price calculation
We prepare a commercial offer based on the configuration, quantity and delivery terms.
4
Supply
After approval, we prepare the kit for shipment according to the agreed terms.
Not sure if it's a good fit Rotor Stator Set 2L6+++?
Send the equipment model, a photo of the current part or the material type. We will help check a suitable solution.
